REALITY CAPTURE SERVICES
Capture High-Precision Field Data with Advanced 3D Reality Capture.
At times, existing field conditions do not correspond with initial blueprints, or drawing archives may be missing altogether. Manual measurements lead to inaccurate baselines, causing costly delays, unexpected RFIs, and design conflicts once construction begins on-site.
Modulus Consulting provides comprehensive reality capture solutions for architects, general contractors, structural engineers, and building owners. Based in San Francisco, our team uses state-of-the-art 3d laser scanning and lidar scanning technology to capture digital field conditions with millimeter-level precision.
Whether you need a full existing conditions survey, site progress tracking, or direct reality capture bim integration, our specialists deliver clear digital site models that keep design and construction workflows moving forward smoothly.
We offer a complete range of reality capture capabilities, including:
- High-precision building laser scanning for architectural, structural, and MEP systems
- On-demand laser scanning services for commercial retrofits and renovations
- Complete construction laser scanning for site progress documentation and QA/QC
- Conversion of high-density point clouds into parametric Revit models
- Strategic 3d reality capture for historic preservation and adaptive reuse
- Verification of structural deflections, slab flatness, and as-built placement
- Reliable field management from a 100% US-owned and operated laser scanning company
- Seamless cloud hosting of digital twins and 360-degree virtual site walks
As a leading provider of digital site documentation, we eliminate guesswork from the field. Our team blends real-world construction knowledge with advanced scanning software to deliver actionable site datasets tailored to your project goals.
REALITY CAPTURE CAPABILITIES & WORKFLOWS
Accurate Digital Site Models Built for Design and Construction.
Deploying high-precision scanning hardware requires trade awareness, field experience, and disciplined processing. We structure our offerings to support every phase of your project lifecycle:
|
Service Area |
Deliverables & Workflows |
Key Benefit |
|
3D Laser & LiDAR Scanning |
High-density point cloud acquisition, terrestrial laser scan registration, and colorized 3D scans |
Replaces manual field measuring with millimeter-accurate spatial data |
|
Scan-to-BIM & Model Integration |
Converting raw scan files into structured 3D Revit models across LOD 100 through 500 |
Gives design teams an accurate as-built baseline for immediate modeling |
|
Construction Progress & QA/QC |
Milestone scanning, slab flatness audits, structural alignment checks, and deviation reporting |
Identifies construction trade variances before downstream work continues |
|
360 Virtual Site Documentation |
Cloud-hosted virtual tours, panoramic photo logs, and digital twin handovers |
Enables remote site reviews, cutting travel time and improving owner clarity |
Technical Execution
- Data Registration & Processing: We clean, index, and register raw scan point clouds using Autodesk ReCap and Leica Cyclone, delivering optimized, lightweight files.
- Deviation & Variance Analysis: We overlay laser scan point clouds against design models to spot structural deflections, misplaced MEP sleeves, or wall displacements early.
- Seamless BIM Integration: Point clouds are aligned with project coordinates so your team can link scan data directly into Autodesk Revit, Navisworks, or ACC.
WHY CHOOSE MODULUS CONSULTING
US-Based Expertise, High Precision, and Field-Tested Results.
Handling complex scanning hardware and tight project submittals requires a dependable VDC partner. We provide trusted reality capture support tailored to domestic construction workflows:
1. 100% US-Owned & Operated
Our scanning technicians and BIM specialists operate directly within US time zones, offering clear communication and full familiarity with local building codes.
2. State-of-the-Art Hardware & Software
We use industry-leading terrestrial scanners, LiDAR tools, and processing software to ensure fast site capture and fast data turnaround times.
3. Direct Integration with Office Standards
We adapt directly to your firm’s BIM Execution Plan (BEP), shared coordinates, view templates, and family libraries for a frictionless workflow.
FREQUENTLY ASKED QUESTIONS
What is 3D Reality Capture?
3D Reality Capture uses laser scanners, LiDAR sensors, and high-resolution imaging to capture the exact physical dimensions of a building or construction site, converting it into a digital 3D point cloud or BIM model.
What is the difference between LiDAR scanning and terrestrial laser scanning?
Terrestrial laser scanning uses tripod-mounted scanners to achieve millimeter-level accuracy for detailed building geometry. LiDAR scanning can be mobile or aerial, capturing large spatial areas quickly for site context and topological surveys.
How does reality capture integrate into our BIM workflow?
We process raw scan data into registered point cloud files (.RCP/.RCS) that link directly into Autodesk Revit or Navisworks, allowing your team to model or check clashes against exact field conditions.
